ARC Billet Rod 3.595" x .490", Clone

Description

This rod measures 3.595" with a .490" wrist pin and is designed to be used with high-performance pistons. It does not require cutting down the top of the 1982 series Wiseco piston for the Honda GX160, GW200, and 196cc clones. All of ARC's rods are CNC machined from aircraft grade 7075 T-651 aluminum and designed to utilize higher compression rations and high RPM's of OHV racing engines. Key featrures include an oil groove in the crank bore that is fed through a channel in the integrated dipper arm and an oil groove in the wrist pin bore that provides a reservoir of lumbricant to the wrist pin. Bearings and custom designed high tensil strength bolts are included.

Specs

Wrist Pin Bore:	.490"
Bearing Size:	1.183"
Rod Bolt Torque:	170in/lbs. lubricated
