BP2 Grind, Clone, Hemi
Description
- This cam meets lift requirements for stock but has a lot of extra duration producing better horsepower over a broader RPM range. Stock setup can be used, but works even better as a modified cam. This cam will easily allow your motor to turn up into the higher RPM range and will require upgraded spring package if your exhaust and intake systems are upgraded. Billet rod and flywheel required for safety if engine is modified.
- The lobes are hardened for extra durability, extending the life of this cam.
Specs
Engine: | 196cc OHV Clone, 212cc Hemi Predator |
---|---|
Recommended Class: | Builder's Prepared |
Target (MAX) RPM: | 7000+ |
Spring Pressure (In / Ex): | 26 lbs |
Valve Lash (In/Ex): | .003" |
Ignition Timing: | 32 Deg BTDC |
Profile
Intake | Exhaust | |
---|---|---|
Open: | 39.0 BTDC | 78.0 BBDC |
Close: | 76.5 ABDC | 36.0 ATDC |
Lift: | .224" | .231" |
C/L: | 109.0 ATDC | 111.0 BTDC |
DUR @ 50: | 246.5 Deg | 245.5 Deg |
Any camshaft that is not in stock will need to be manufactured. This may cause a delay of 5-7 business days.
